CNC gear hobbing machine
Dimension :
Dimension
Germany-made Bosch rexroth MTX-micro type, High-level five-axis computer system,with KASHIFUJI machine body,Max Cutting Dia 300φ,max module8,max travel of cutter saddle 300,max cutting tilt angle±45°, The number of cutting teeth 4~1023、 the maximum cutting lead is 45000mm 、,Center distance between Hob&Table 20~280,Table dia 300,Table hole 82,Max Hob size 150φ×180L,standard hob dia 40φ,Taper of spindle nose NT45, Hob travel distance130,Hob rpm 400rpm,Max worktable rpm 40rpm,NC5axis(table rotation,feed up/down,feed back/forth,hob head tilting,Main motor 15kw,Floor area 3390×3010mm,weight 8500kgs,cutting function：1.one auto cycle,2.two auto cycle,3.Crowning cutting,4.Inclined cutting,5.step cutting,6.worm cutting
CNC Gear hobbing machine
Dimension :
Dimension
MAX DIA 1500φ、MAX MODULE 20、TABLE SIZE 1300、CUTTING DIA 180~280、FANUC 0-MC、MACHINE SIZE：6100×3370×3205、CNC 4AXES
5 Axis CNC Gear hobbing machine
Dimension :
Dimension
Max workpiace diaφ200、Max dia pitch M6、Max axial traver 250、Max radial travel 225、High worktable to cnter of hob sprindl 190~440、Center distance between hob sprindle and work spindle 25~250mm、Max hob dia×length 130×230、Max hob shift 180、Hob speed range 100~1000rpm、Max table speed 200rpm、Hob head swiveling angle ±45°、Main motor 7.5KW、Net weight 6.5TON、CNC 5 AXIS、Control：MITSUBISHI-MELDASS、Auto loader
5 Axis CNC Hobbing Machine (JAPAN KASHIFUJI)
Dimension :
Dimension
Max workpiece dia 150φ、Max pitch module4、Axial feed travel 400mm、max helix angle ±45°、Max hob shift travel 150、 center distance between hob&table 15~150mm、table top dia 190、hob spindle RPM 100~1330rpm、FANUC 18I MB
5 Axis CNC Hobbing Machine (JAPAN KASHIFUJI)
Dimension :
Dimension
Max workpiece dia 150φ、Max pitch module4、Axial feed travel 400mm、max helix angle ±45°、Max hob shift travel 150、 center distance between hob&table 15~150mm、table top dia 190、hob spindle RPM 100~850rpm、FANUC 15M、machine weight 7000kg
5 Axis CNC Hobbing Machine (JAPAN KASHIFUJI)
Dimension :
Dimension
Max workpiece dia 150φ、Max pitch module4、Axial feed travel 400mm、max helix angle ±45°、Max hob shift travel 150、 center distance between hob&table 15~150mm、table top dia 190、hob spindle RPM 100~850rpm、FANUC 15M、machine weight 7000kg，Auto loader
5 Axis CNC Hobbing Machine (JAPAN KASHIFUJI)
Dimension :
Dimension
Max workpiece dia 150φ、Max pitch module4、Axial feed travel 400mm、max helix angle ±45°、Max hob shift travel 150、 center distance between hob&table 15~150mm、table top dia 190、hob spindle RPM 100~850rpm、FANUC 15M、machine weight 7000kg
5 Axis CNC Hobbing Machine
Dimension :
Dimension
Max workpiece dia 220、Max module7、Max axial feed travel 300、Max hob head swivel ±45°、Max hob size dia×length 150φ×200l、Max hob shift travel 150、Taper of spindle Nose NT40、Max revolution of hob 50~500R.P.M、Fanuc 0i-MF Plus
5 AXIS CNC HOBBING MACHINE
Dimension :
Dimension
Max workpiece dia 400、Max Pitch module 7、Axial feed travel 300、max helix angle 45°、max hob shif travel 150、center distance between hob&table 35~305、table size 460φ、hob spindle RPM10~500rpm、FANUC 10M、maachine weight 9800kg
5 AXIS CNC HOBBING MACHINE
Dimension :
Dimension
Max workpiece dia 400、Max Pitch module 7、Axial feed travel 300、max helix angle 45°、max hob shif travel 150、center distance between hob&table 35~305、table size 460φ、hob spindle RPM10~500rpm、FANUC 10M、maachine weight 9800kg、Auto Magazine Feed Attachment
5 AXIS CNC HOBBING MACHINE
Dimension :
Dimension
Max workpiece dia 400、Max Pitch module 7、Axial feed travel 300、max helix angle 45°、max hob shif travel 150、center distance between hob&table 35~305、table size 460φ、hob spindle RPM10~500rpm、FANUC 10M、maachine weight 9800kg
5 Axis CNC Gear hobbing machine
Dimension :
Dimension
Max workpiece dia 130、Max module 3、FANUC 160i-M、Axial 5、Max axial slide travel250、Hob swivel angle ±45°、Max hob speed 3000rpm、Max workspindle speed 1000rpm、Max hob dia 80、Max hob length total length170/245、Max hob shift travel 170、Hob drive 14KW、Table surface dia 160、Machine weight 11000KG、Auto Magazine Feed Attachment
