CNC Gear hobbing machine
Dimension :
Dimension
MAX DIA 1500φ、MAX MODULE 20、TABLE SIZE 1300、CUTTING DIA 180~280、FANUC 0-MC、MACHINE SIZE：6100×3370×3205、CNC 4AXES
5 Axis CNC Gear hobbing machine
Dimension :
Dimension
Max workpiace diaφ200、Max dia pitch M6、Max axial traver 250、Max radial travel 225、High worktable to cnter of hob sprindl 190~440、Center distance between hob sprindle and work spindle 25~250mm、Max hob dia×length 130×230、Max hob shift 180、Hob speed range 100~1000rpm、Max table speed 200rpm、Hob head swiveling angle ±45°、Main motor 7.5KW、Net weight 6.5TON、CNC 5 AXIS、Control：MITSUBISHI-MELDASS、Auto loader
Gear hobbing machine
Dimension :
Dimension
Max dia 1260(without support)、780(with support)、Max module 10、Table dia 780、max axial feed travel 430、Max hob size 155φ×200l、Main motor 5hp、Machine weight 8200kg
HEAVY DUTY PRECISION HOBBING MACHINE
Dimension :
Dimension
Max dia 1800(without support)、1060(with support)、Max module 16、sliding distance of hob saddie 500、distance between centers of two arbors 110~1100、spindle rpm 20~80、hob size 230φ×280φ、table size 1060、bore of table 200、main motor 11kw、machine size 4175L×2025W×2590H、machine weith 16ton
Production Gear hobbing machine
Dimension :
Dimension
MAX DIA500φ、(without support)、Max dia 300φ(with support)、MAX MODULE 3、max travel of hob saddle 210mm、min center distance between hob arbor and work arbor 10mm、Dia of table 300、Hob speeds 28~400rpm、Hob size 80φ×90L、Machine weight 1800kg
Horizontal Precision gear hobbing machine
Dimension :
Dimension
Max dia 120、Max cutting length 160、Max module 2、Max hob spindle speed、1800rpm、
Precision Gear Hobbing Machine
Dimension :
Dimension
MAX DIA120φ、MAX MODULE2
Precision Gear Hobbing Machine
Dimension :
Dimension
MAX DIA120φ、MAX MODULE2
Precision Gear Hobbing Machine
Dimension :
Dimension
MAX DIA120φ、MAX MODULE2
Precision Gear Hobbing Machine
Dimension :
Dimension
MAX DIA120φ、MAX MODULE2
Gear hobbing machine
Dimension :
Dimension
MAX DIA 70φ、MAX MODULE 1.5、MAX LENGTH 100
Gear hobbing machine
Dimension :
Dimension
MAX DIA 70φ、MAX MODULE 1.5、MAX LENGTH 100
Gear hobbing machine
Dimension :
Dimension
MAX DIA 70φ、MAX MODULE 1.5、MAX LENGTH 100
Gear hobbing machine
Dimension :
Dimension
Max dia660、Max module6、Auto cycle type cutting table size 530、Max travel of cutter saddle 360、Cutter speed 8 changes68~220rpm、Nnet weight 4300kg
Gear hobbing machine
Dimension :
Dimension
Max dia660、Max module6、Auto 2 cycle type cutting table size 530、Max travel of cutter saddle 360、Cutter speed 8 changes68~220rpm、Nnet weight 4300kg
Gear hobbing machine
Dimension :
Dimension
MAX DIA 1800φ、MAX MODULE 15、Table Dia 970mm
HOBBING MACHINE
Dimension :
Dimension
Max workpiece dia 250、max module 4.5、max hobbing length 190、table dia 200、max rpm 450rpm、machine weight 1900kg
Gear hobbing machine (High production)
Dimension :
Dimension
Max Dia 600φ、Max Module 8、Table Dia 570φ、1. Hydraulic Auto 2 Cycle Cutting System、2. Auto Hob Shifting Device、3. Auto Hydraulic Support Lift
Gear hobbing machine (High production)
Dimension :
Dimension
Max Dia 600φ、Max Module 8、Table Dia 570φ、1. Hydraulic Auto 2 Cycle Cutting System、2. Auto Hob Shifting Device、3. Auto Hydraulic Support Lift
Gear Hobbing Machine
Dimension :
Dimension
Max Dia 600φ、Table size 420φ、Max Module 5
