Hypoid gear grinder machine
Dimension :
Dimension
MAX DIA (34")、861mm、2DP (MODULE 12)、Cone distance(maximum30° Spiral angle and 12" diameter wheel 381mm、depth of taper 6"、feed(sec/tooth) 1.9to11.8s econds、feed motor 1500rpm
NC Hypoid Gear Generator
Dimension :
Dimension
FANUC Power Mate、Pitch diameter (Maximum) 10 to 1 ratio 10 1/2 (266mm )、21;2 to 1 ratio (10 mod. )、Face width (Maximum) 1 5/8"(41mm)、Full depth (Maximum)750"(19mm )、Main motor 50 cycle 1500RPM、Net weight 6123KGvv
NC Hypoid Gear Generator
Dimension :
Dimension
Mitsubishi 3 Axis、Diametral pitch 12.7MOD、Cone distance (30° spiral angle and 12" cutter) 230mm、Work head angle 12°~90°、Maximum gear pitch diameter 10:1 (460mm)、2:1(406mm)、1:1(324mm)、Face width (maximum)70mm、Nmber of teeth 5~150mm、Diameter of taper hole at large end 100mm、Taper per foot 15mm、Depth of taper 150mm、Diaameter of hole through spindle 78mm、Cutter speeds 17~115rpm、Feed 9~80 seconds、Net weight 10750kg
NC Hypoid Gear Generator
Dimension :
Dimension
Mitsubishi 3軸(Mldas 64)、 Max.cone distance : 107 mm, Max. pitch diameter (30° spiral angal) : 10 to 1 ratio : 215 mm, 2 to 1 ratio : 190 : mm, 1 to 1 ratio : 152 mm, Max. face width: 31.7 mm, Max depth : 15.8 mm, Diametral pitch, coarsest : 6.35 Mod. , WORK SPINDLE Diameter of taper hole at large end: 23 mm Taper per foot : 15.5 mm, Depth of taper: 152.4 mm, Diameter of hole through spindle: 61.9 mm Work Head Settings Offset above center, maximum :76.2 mm, Offset below center, maximum : 76.2 mm, Distance from machine center to nose of spindle (maximum) : 31.7 mm、machine weight 7500KG
NC Hypoid Gear Generator
Dimension :
Dimension
FANUC Power Mate、Pitch diameter (Maximum) 10 to 1 ratio 10 1/2 (266mm )、21;2 to 1 ratio (10 mod. )、Face width (Maximum) 1 5/8"(41mm)、Full depth (Maximum)750"(19mm )、Main motor 50 cycle 1500RPM、Net weight 6123KGvv
Hypoid Gear Generator
Dimension :
Dimension
Pitch diameter (Maximum) 10 to 1 ratio 10 1/2 (266mm )、21;2 to 1 ratio (10 mod. )、Face width (Maximum) 1 5/8"(41mm)、Full depth (Maximum)750"(19mm )、Main motor 50 cycle 1500RPM、Net weight 6123KGvv
NC Hypoid Gear Generator
Dimension :
Dimension
Mitsubishi 3 Axis、Diametral pitch 12.7MOD、Cone distance (30° spiral angle and 12" cutter) 230mm、Work head angle 12°~90°、Maximum gear pitch diameter 10:1 (460mm)、2:1(406mm)、1:1(324mm)、Face width (maximum)70mm、Nmber of teeth 5~150mm、Diameter of taper hole at large end 100mm、Taper per foot 15mm、Depth of taper 150mm、Diaameter of hole through spindle 78mm、Cutter speeds 17~115rpm、Feed 9~80 seconds、Net weight 10750kg
NC Hypoid Gear Generator
Dimension :
Dimension
Mitsubishi 3軸(Mldas 64)、 Max.cone distance : 107 mm, Max. pitch diameter (30° spiral angal) : 10 to 1 ratio : 215 mm, 2 to 1 ratio : 190 : mm, 1 to 1 ratio : 152 mm, Max. face width: 31.7 mm, Max depth : 15.8 mm, Diametral pitch, coarsest : 6.35 Mod. , WORK SPINDLE Diameter of taper hole at large end: 23 mm Taper per foot : 15.5 mm, Depth of taper: 152.4 mm, Diameter of hole through spindle: 61.9 mm Work Head Settings Offset above center, maximum :76.2 mm, Offset below center, maximum : 76.2 mm, Distance from machine center to nose of spindle (maximum) : 31.7 mm、machine weight 7500KG
Hypoid Gear Generator
Dimension :
Dimension
Max. cone distance 30° spiral angle & 12" cutter 228.6、Extreme ratio 10:1、Max. gear pitch diameter (30° spiral angle )、10:1 ratio460、2:1 ratio406、1:1 ratio323、Coarsest diametral pitch12.7(DP2)、Max. full deep25.4mm、Max. face width69.9mm、Number of teeth5~150、Cutter speeds17~115rpm、Feed (seconds per tooth)9~80sec/tooth
Hypoid generator (spiral bevel gear machine)
Dimension :
Dimension
MAX DIAMETER 457φ、MAX MODULE 10、Longest pitch come228、Max ration of gear,cut 1:10、CUTTING STROKES29~141rpm、Power of main motor 3.75KW、Floor space1725×2440、New weight 6500
Hypoid lapper
Dimension :
Dimension
Maximum gear diameter 266mm、Maximum pinion diameter 152mm、Offset of gear spindle above or below center of pinion spindle 95mm、Pinion spindle Diameter of taper hole at large and 100mm、Main moter 5HP/1800rpm、Taper per foot 13mm、Floor space1800mm×16200mm、Net weight 4195kg
Worm milling machine
Dimension :
Dimension
center height 210mm、max length of hob 1000、max dia of hob 200、swing dia over bed 420、speeds 28rpm~250rpm、chuck dia 250vv with rapid travel of carriage
Thread screw cutting machine
Dimension :
Dimension
MAX LENGTH 550、MAX DIAMETER 300φ、MIN DIAMETER 5
Hypoid gear grinder machine
Dimension :
Dimension
max. wheel diameter 700 mm、gear width 250 mm、max. module 7 、min. number of teeth 16 、max.helical angle +/- 30 °、slide stroke 290 mm、clamping length 256 - 570 mm、grinding worm dia. 280 - 400 mm、workpiece weight 300 kg、connected electrical load 30KVA、N weight of mchine 9700kg
Ginding worm profiling machine (Dressing machine)
Dimension :
Dimension
Module 0.5~9、grinding wheel Dia 270~400、Width 62、84、104
Balancing machine
Dimension :
Dimension
Maximum outer diameter 520φ、working length 600、HP 0.55/1.1KW、current 1.47/2.8A、 speed 710/1425rpm
Spur and helical gear generating grinding machine
Dimension :
Dimension
tip circle diameter max 350φ、root circle diameter min(13)30mm、no.of teeth min/max 5...140、rotary table load max 200kp、grinding wheel diam. min/max 270/350mm(200/280mm)、grinding wheel bore/width 127/32mm(51/25mm)、speed of grinding wheel 1900rpm(2280rpm)、adjustment of stroke position 120mm、connected load approx 8.5KW、5900
Hypoid gear grinder machine
Dimension :
Dimension
MAX DIA (34")、861mm、2DP (MODULE 12)、Cone distance(maximum30° Spiral angle and 12" diameter wheel 381mm、depth of taper 6"、feed(sec/tooth) 1.9to11.8s econds、feed motor 1500rpm
Key way milling machine
Dimension :
Dimension
MAX CUTTING 400L
Shaving cutter sharpener
Dimension :
Dimension
MAX GRINDING 350
