CNC 車床
Dimension :
Dimension
VturnII-26 Y -- Swing over bed 780φ、BETWEEN CENTERS 475φ、Max turning dia 330φ、Std turning dia 285φ、C axis indexing deg 0.001、FANUC 18IT(1980M)、X axis：195、Z axis：475、Y axis：±55、Spindle speed 3500rpm、High power and high spindle Nose(Chuck)A2-8、 torque spindle spindle bore 86、Turret No of tools 12 turret tool shank size 25、Turret max boring bar dia 30、Turret milling 3000rpm、High point rigid tapping Exchange time (T-T)sec 0.3、Tailstock Quill dia85、MT5、Quill stroke 120、Feed rate rapid X axis：18000、Z axis：20000、Y axis：7500、Machine size 2800×2073×2175、Machine Net weight 5600kg
CNC LATHE
Dimension :
Dimension
Swing over bed 670、Between centers620、Max turning dia 310、std turning dia 290、Spindle speed 3500rpm、High power and high torque spindle、Spindle Nose(chuck)A2-8(10")、spindle bore86、Turret No.of tools 12、Turret tool shank size 25、turret max boring bar dia 40、turret milling 3000rpm、single point rigid tapping exchange time (T-T)sec 0.3、Tailstock Quill dia 85、MT5、Quill stroke 120、Feed rate Rapid X：20000、Z：24000、Motor 15/18.5KW、servo motor kw X：3.0、Z：4.0、FANUC 18iT、machine net weight 5300kg
CNC MILL-TURNING CENTER
Dimension :
Dimension
Fanuc 11T、Max swing 500φ、Chuck size 8"(203φ)、X axis 205、Z axis 400、C axis (milling axis)360°、Spindle rpm 40~3150、Spindle drive motor DC 22/15、NET weight 5500kg
CNC LATHE
Dimension :
Dimension
Max swing over slant bed 470、Max turning Dia 280、Center distance 560、X-axis 160、Z-Axis 435、Tool Positions 8 total、Spindle Nose ASA-A1-6、Spindle Horsepower 15HP、FANUC 10T
CNC LATHE
Dimension :
Dimension
Max swing over slant bed 470、Max turning Dia 280、Center distance 560、X-axis 160、Z-Axis 435、Tool Positions 8 total、Spindle Nose ASA-A1-6、Spindle Horsepower 15HP、FANUC 10T
CNC LATHE
Dimension :
Dimension
Max swing over slant bed 470、Max turning Dia 280、Center distance 560、X-axis 160、Z-Axis 435、Tool Positions 8 total、Spindle Nose ASA-A1-6、Spindle Horsepower 15HP、FANUC 10T
CNC Auto lathes
Dimension :
Dimension
Max work length for bar work 150、for chuck work 80、 bar capacity round for main spindle 12~34φ、spindle speed 200~6000rpm、Spindle Nose 36、Hydraulic cylinder X axis 100、Z axis 185、Turret stations 8、Main motor 3.7/5.5kw、machine weight 2300kg
CNC Auto lathes
Dimension :
Dimension
Max work length for bar work 150、for chuck work 80、 bar capacity round for main spindle 12~42φ、spindle speed range 170~5000rpm、FANUC 21iT、 spindle nose 43、Hydraulic cylinder X axis 100、Z axis 185、Turret stations 8、Main motor 5.5/7.5KW、weight 2300KG
CNC Auto lathes
Dimension :
Dimension
Max work length for bar work 150、for chuck work 80、 bar capacity round for main spindle 12~34φ、spindle speed 200~6000rpm、Spindle Nose 36、Hydraulic cylinder X axis 100、Z axis 185、Turret stations 8、Main motor 3.7/5.5kw、machine weight 2300kg
CNC Auto lathes
Dimension :
Dimension
Max machinable dia 18、Mainspindle speed 200~10000rpm、Back spindle speed 200~8000rpm、TSUGAMI-FANUC LK1、Total number of tools 18、Rapid traverse rate 18mm/min(X1、Y12mm/min)、Main spindle motor 1.1/3.7kw、Width×Depth×Height 1770×1150×1685、Net weight 2200kg
CNC Auto lathes
Dimension :
Dimension
Max machinable dia 18、Mainspindle speed 200~10000rpm、Back spindle speed 200~5000rpm、TSUGAMI-FANUC LB2、Total number of tools 10、Rapid traverse rate 18mm/min(X1、Y12mm/min)、Main spindle motor 1.1/3.7kw、Width×Depth×Height 1600×895×1600、Net weight 1600kg
CNC Auto lathes
Dimension :
Dimension
Max machinable dia 18、Mainspindle speed 200~10000rpm、Back spindle speed 200~5000rpm、TSUGAMI-FANUC LA1、Totla number of tools 18、Rapid traverse rate 18mm/min(X1、Y12mm/min)、Main spindle motor 1.1/3.7kw、Net weight 1700kg
CNC vertical turning center
Dimension :
Dimension
Table dia： 1650φ、MAX Swing： 2030、MAX Turning height 1825、mill head BT 50/BT40、FANUC 0ITD、ATC 30
Vertical turning lathe (single column mills)
Dimension :
Dimension
Max turning dia7000、table dia3000、Fanuc 0T-B、max height between table and toolholder2200、max weight of work piece 15Ton、veritcal traverse of toolhead 1200、ATC 40、main motor 45kw×6P
