- Manufacturer KASHIFUJI
- Specification KN-150
- Year
- Location Ryokuta 1st Factory
Dimension
Max workpiece dia 150φ、Max pitch module4、Axial feed travel 400mm、max helix angle ±45°、Max hob shift travel 150、 center distance between hob&table 15~150mm、table top dia 190、hob spindle RPM 100~850rpm、FANUC 15M、machine weight 7000kg
